| SPECIFICATION | UNIT | HIC-150 | HIC-300 | HIC-450 | |
|---|---|---|---|---|---|
| Capacity | Height of centre | mm | 102 | 102 | 102 |
| Max. Table Stak | mm | 160 | 325 | 475 | |
| Min. I.D. | mm | 8 | 8 | 8 | |
| Max. I.D. | mm | 100 | 100 | 130 | |
| Table | Swiveling angle | deg. | ±9° | +10° -4° | +9° -3° |
| ● "Table speed Mech. 4 step | mm/min | 140-260-370-700 | |||
| Electric motor required | HP/rpm | 0.5 OR 0.37 kw. X 1440 | |||
| ● "Hy. Speed infinitely variable | met/min | 0.1 to 2.5 | |||
| Hy. Power pack electric motor | HP/rpm | TOR 0.75 kw. 1441 | |||
| Work Head | Taper in quile | M.T | 3 | ||
| Spindle Speed (3 Rang) | rpm | 90-210-360 | 90-180-360 | ||
| Electric Motor (3 Phase) | HP/rpm | 0.5 x 1440 | |||
| Internal grinding | Spindle size | mm | 200 x 60 | 200 x 60 | 200 x 60 |
| Spindle speed | rpm | 12000 | 12000 | 16000 | |
| electric motor required 3 phase | HP/rpm | 1 x 2800 | |||
| Coolant tank | Coolant tank | liter | 35 | 35 | 50 |
| Coolant pump 3 phase | HP | 0.15 | |||
| Total weight | machine approx | Kg. | 600 | 900 | 1400 |
The company assures its customers of consistence in quality as well as value for money. The company offers its quality products at very competitive prices. The company invites qll types of enquiries for its product range and also welcome any special requirements and suggestions.
